Evolution 230-HDX Specifiche Scaricare il pdf (Pagina 7)

www.evolutionpowertools.com

Note: The vibration measurement was made

under standard conditions in accordance with:

BS EN 61029-1:2009

The declared vibration total value has been

measured in accordance with a standard test

method and may be used for comparing one

tool with another.

The declared vibration total value may also be

used in a preliminary assessment of exposure.

VIBRATION

WARNING: When using this machine

the operator can be exposed to high levels of

vibration transmitted to the hand and arm. It

is possible that the operator could develop

“Vibration white finger disease” (Raynaud

syndrome). This condition can reduce the

sensitivity of the hand to temperature as well

as producing general numbness. Prolonged

or regular users of this machine should

monitor the condition of their hands and

fingers closely. If any of the symptoms become

evident, seek immediate medical advice.

• Themeasurementandassessmentof

human exposure to hand-transmitted

vibration in the workplace is given in:

BS EN ISO 5349-1:2001 and

BS EN ISO 5349-2:2002

• Manyfactorscaninfluencetheactual

vibration level during operation e.g. the

work surfaces condition and orientation

and the type and condition of the machine

being used. Before each use, such factors

should be assessed, and where possible

appropriate working practices adopted.

Managing these factors can help reduce

the effects of vibration:

Handling

• Handlethemachinewithcare,allowing

the machine to do the work.

• Avoidusingexcessivephysicalefforton

any of the machine’s controls.

• Consideryoursecurityandstability,and

the orientation of the machine during use.

Work Surface

• Considertheworksurfacematerial;

its condition, density, strength,

rigidity and orientation.

WARNING: The vibration emission during

actual use of the power tool can differ from the

declared total value depending on the ways

in which the tool is used. The need to identify

safety measures and to protect the operator

are based on an estimation of exposure in the

actual conditions of use (taking account of all

parts of the operating cycle, such as the times

the tool is switched off, when it is running idle,

in addition to trigger time).

LABELS & SYMBOLS

WARNING: Do not operate this machine

if warning and/or instruction labels are

missing or damaged. Contact Evolution

Power Tools for replacement labels.

Note: All or some of the following symbols

may appear in the manual or on the product.

1 2 3 4 5 6 7 8 9 10 11 12 ... 23 24
